Foodline Machinery flake ice machines provide fast-deploy, high-efficiency cooling for global seafood, food processing, and cold chain sectors. Built with plug-and-play design, Danfoss inverter tech, and PLC automation, it delivers 24/7 dry flake ice with maximum power savings.
l 1–20TPD Flexible Output With Intelligent PLC Control & Full Safety Protection
l Plug & Play Integrated Unit, Fully Operational After Water & Power Connection
l 6-Min Fast Ice Output ,40% Higher Efficiency For Rapid Cooling Production
l 30% Energy Saving , Danfoss Inverter Compressor & Optimized Refrigeration System
l Standard 2mm Dry Flake Ice for Anti-caking & High-standard Fresh Preservation
l Full 304SS Food-grade Structure, CE Certified for Long-term Stable Operation
Foodline Machinery industrial flake ice machine supports full commercial customization, including 1–20TPD adjustable ice output, optional air-cooled and water-cooled models, and customized working solutions for freshwater and seawater conditions. The equipment allows efficient rapid ice making, multi-scenario industrial and commercial applications, and intelligent PLC control interfaces. All operating parameters, including ice output, running status, and defrost cycle, can be automatically controlled and monitored in real time for stable and energy-saving ice production operation.
| Specifications of 5Ton Flake Ice Machine | |
| Product Name | 5 Ton Flake Ice Machine |
| Ice Output | 5000kg/24h |
| Refrigeration Capacity | 37.2KW |
| Evaporating Temperature | -20℃ |
| Condensing Temperature | 40℃ |
| Installation Power | 22.05KW |
| Compressor Input Power | 20.2KW |
| Power Supply | 3P-380V-50Hz |
| Refrigerant | R404A |
| Ice Thickness | 1.5mm–2.2mm |
| Water Consumption | 0.2 m³/h |
| Net Weight | 1000kg |
| Dimensions (LWH) | 2000mm x 1600mm x 1650mm |
Used in offshore fishery and seafood processing plants. Produces dry 3mm flake ice for rapid fresh-keeping, supports 24h continuous stable ice production, effectively lowering seafood wastage.
Installed in meat and vegetable food processing factories. Equipped with Danfoss inverter compressor to cut power consumption, intelligent PLC control ensures long-term reliable operation.
Deployed for coastal seafood markets and aquaculture farms across Queensland and Victoria. Full 304 stainless steel corrosion-resistant structure, plug-and-play setup, customized ice output meets diverse daily preservation demands.
